PRO 8" Shallow Neodymium Full-Range Loudspeaker 200 Watts Rms 8-Ohm

DS18 PRO-NS8 8" Shallow Neodymium Mid-Range Loudspeaker 400 Watts 8-Ohm DS18's new Neodymium shallow speakers were designed...
Vendor: DS18
SKU: PRO-NS8
Availability: Out Of Stock
Product type: Car Audio : Loudspeakers
$95.95
$95.95
Please hurry! Only 0 left in stock
Subtotal: $95.95
10 customers are viewing this product

Free Shipping

Free standard shipping on select products

PRO 8" Shallow Neodymium Full-Range Loudspeaker 200 Watts Rms 8-Ohm

PRO 8" Shallow Neodymium Full-Range Loudspeaker 200 Watts Rms 8-Ohm

$95.95

PRO 8" Shallow Neodymium Full-Range Loudspeaker 200 Watts Rms 8-Ohm

$95.95

DS18 PRO-NS8 8" Shallow Neodymium Mid-Range Loudspeaker 400 Watts 8-Ohm

DS18's new Neodymium shallow speakers were designed to give you maximum loudness and volume all while keeping a nice small framed package. Most neo speakers are full size and take up a good amount of mounting depth, with these new Neo slim speakers, you can get that insane neodymium loudness where there is not much room for full size speakers.

This 8" inch neodymium 2" voice coil Midrange speaker takes 200w RMS and 400w Peak power, so you know they will get loud easily. The 96dB sensitivity rating will be sure to give you plenty of volume as well for years and years of enjoyment.

Highlights
  • Neodymium Slim design so now you can get all that neodymium power and volume in a slim frame.
  • High efficiency 8 ohm 2 inch voice coil that handles 200w RMS and 400w peak power for extreme loudness and frequency precision.
  • Shallow mounting depth of only 2.48 inches, these neodymium midrange speakers can fit almost anywhere you need great sound and max volume.

shallow neodymium mid-range loudspeaker

shallow neodymium mid-range loudspeaker

shallow neodymium mid-range loudspeaker

shallow neodymium mid-range loudspeaker

shallow neodymium mid-range loudspeaker

Technical Details
                                                      PRO-NS8 Product Manual

Nominal Diameter 8"/208mm
Nominal Impedance 8 Ohms
RMS Power Handling 200W
MAX Power Handling 400W
Sensitivity (1w/1m) 96 dB
Frequency Response 97Hz - 12KHz
Recommended Hi Pass Crossover 160Hz
Pair or Single Single
Voice Coil Diameter 2"/50.8mm
Voice Coil Former Material KSV
Winding Material Copper
Cone Material Paper
Dust Cap Material paper
Surround Materia Cloth
Basket Material Steel
Basket Color Glossy Red
Magnet Material Neodymium
Magnet Weight 3.32oz
THIELE & SMALL PARAMETERS
Equivalent Volume 5.48l / 0.193ft3
Excursion (one way) 2 mm
Free Air Resonance 120Hz
Mechanical Factor 3.781
Electrical Factor 0.952
Total Factor 0.761
Mechanical Mass 13.242g
Mechanical Compliance 162m cm/N
BL Factor 6.029
Voice Coil Inductance 7.011mH
Cone Area 213.825 Cm3
DC Resistance 6.5 ohms
Mechanical Mass w/o air/ 13.07g
MEASUREMENTS
Overall Diameter 8.2"
Overall Depth 2.67"
Front Mount Baffle Cutout 7.12"
Mounting Depth 2.48"
Motor Diameter 4.33"
