NVY 4-Channel Full-Range IPX7 Submersible Marine and Powersports Amplifier 120 x 4 @ 4-Ohm Watts RMS

DS18 HYDRO NVY-IPX7.4 Full-Range Class D Marine 4-Channel Amplifier 120 x 4 @4 Ohm Watts Waterproof IP67...
Vendor: DS18
SKU: NVY-IPX7.4
Availability: Out Of Stock
Product type: Marine And Off Road : Amplifiers
$700.00
$700.00
Please hurry! Only 0 left in stock
Subtotal: $700.00
10 customers are viewing this product

Free Shipping

Free standard shipping on select products

NVY 4-Channel Full-Range IPX7 Submersible Marine and Powersports Amplifier 120 x 4 @ 4-Ohm Watts RMS

NVY 4-Channel Full-Range IPX7 Submersible Marine and Powersports Amplifier 120 x 4 @ 4-Ohm Watts RMS

$700.00

NVY 4-Channel Full-Range IPX7 Submersible Marine and Powersports Amplifier 120 x 4 @ 4-Ohm Watts RMS

$700.00

DS18 HYDRO NVY-IPX7.4 Full-Range Class D Marine 4-Channel Amplifier 120 x 4 @4 Ohm Watts Waterproof IP67




The NVY series was manufactured to put power back into your hands whether you’re out on the great blue or maneuvering on the dirt path less traveled.

Our latest amplifier added to this series has an IPX waterproof rating of IP77, giving this fortified beast of a machine the ability to be submerged in water as deep as 1 meter for up to 30 minutes. It also has a 2 CH/ 4 CH input selector giving you complete control over how much power gets designated to each of your speakers.

Place this amplifier anywhere using our Direct Power harness design manufactured to give you creative control over where you get the wave making tunes on your marine vehicle.

Order this amplifier while supplies last!

Highlights

  • The included marine grade fuse and fuse holder that is connected inline with your main power wire, will help with ultimate protection against the elements.
  • Latest Digital amplifier design with SMC technology
  • Submergible IP67 Waterproof Rating
  • UV, Salt and Fog protection
  • 2 CH / 4 CH Input Selector
  • Maximum output of 350W x 2 CH bridged at 4-Ohms, 200W x 4 CH at 2-Ohms, and 120W x 4 CH at 4-Ohms

Great For:

    • Marine
    • Off road
    • DIY Projects

Technical Details
               NVY-IPX7.4 Product Manual

Specifications
POWER
Total Watts (Peak)  1440 Watts
RMS Power @ 4 ohm  4 x 120 Watts
RMS Power @ 2 ohm 4 x 200 Watts
RMS Power @ 4 ohm Bridge  2 x 350 Watts
AUDIO
Frequency Response 20Hz - 20KHz
Signal to Noise Ratio 1W@4Ω  >90 dB
Efficiency @ 4 ohm  94%
Input Impedance >20KΩ
Channel Separation  >-70 dB
Total Harmonic Distortion (THD)  <0.1 %
Low Level Input Range  270mV - 5.6V
Selectable X-Over  HPF/FULL/LPF
X-Over Filter Range 50Hz-4KHz
FEATURES
Amplifier Class  Digital (D)
Amplifier Type Full Range Digital Marine Amplifier
Number of Channels 4
Minimum Impedance  2 OHM / Ch (4 OHM Bridge)
LED Indicator Protection (Red) | Power (Blue)
Power Input Size 8 Ga
Fuse  2 x 40A
Thermal Protection  Yes
Over-Load Protection  Yes
Short Circuit Output Protection  Yes
Voltage Input Protection  Yes (9.5-16V)
Body Color | Finish  Black Anodize
2CH | 4CH Input Selector Yes
Waterproof Rating  IP67
UV / Salt Fog Protection  Yes
Direct Power Harness Design  Yes
Surface Mount Component Technology  Yes
Marine Grade Fuse Holder  Yes
MEASUREMENT
Overall Length  10" / 253mm
Overall Wide  4.5" / 116mm
Overall Height  1.9" / 48.5mm
Heatsink Length  8.5" / 216mm
Gross Single Unit Weight  1.8Kg
