1" Throat Twist On Neodymium Driver 160 Watts 1.5" Composite Polyimide Vc 8-Ohm

DS18 PRO-DRNSC1.5 1" Screw On Compression Driver with 1.5" Polyimide VC 8 ohm PRO-DRNSC1.5 The PRO-DRNSC1.5 boasts unmatched power handling for...
Vendor: DS18
SKU: PRO-DRNSC1.5
Availability: Out Of Stock
Product type: Car Audio : Drivers
$95.95
$95.95
Please hurry! Only 0 left in stock
Subtotal: $95.95
10 customers are viewing this product

Free Shipping

Free standard shipping on select products

1" Throat Twist On Neodymium Driver 160 Watts 1.5" Composite Polyimide Vc 8-Ohm

1" Throat Twist On Neodymium Driver 160 Watts 1.5" Composite Polyimide Vc 8-Ohm

$95.95

1" Throat Twist On Neodymium Driver 160 Watts 1.5" Composite Polyimide Vc 8-Ohm

$95.95

DS18 PRO-DRNSC1.5 1" Screw On Compression Driver with 1.5" Polyimide VC 8 ohm

PRO-DRNSC1.5

The PRO-DRNSC1.5 boasts unmatched power handling for the Pro Audio sound you love. This neodymium compression driver ensures unparalleled performance that delivers impressive sound with striking clarity and limitless depth. Equipped with a highly durable 1.5” voice coil, these drivers are guaranteed to perform at their maximum potential for the entirety of any jam session. This compression driver doesn’t draw an excessive amount of power from your amplifier & ensures long lasting performance from your equipment.

Highlights

  • 80W AES Power Handling; 160W Program Power Handling; 320W Peak Power Handling
  • Drop-in voice coils for fast and easy repairs in the rare occasion they are overpowered
  • Screw-On functionality for easy install
  • Neodymium Magnets to ensure the highest efficiency, and power handling, without the bulk of traditional ferrite magnets
  • Compact driver with functionality in spaces most drivers can’t fit
  • Made to fit most standard thread on horn throats
  • 109dB sensitivity for easy climbs to MAX volume

Great For

  • Car Audio
  • Pro Audio
  • DIY Projects
  • Motorcycles
  • Stunt Walls

    Technical Details
                  PRO-DRNSC1.5 Product Manual
    SPECIFICATIONS
    Throat Diameter 1" / 25.4mm
    Installation Type Screw-On
    Nominal Impedance  8 ohms
    AES Power handling 80 W
    Program Power Handling  160 W
    Peak Power handling 320 W
    Sensitivity (1w/1m)  109 dB
    Frequency Response 1K-20KHz
    Recommended Hi Pass Crossover 2KHz
    Pair or Single Single
    MOTOR
    Voice Coil Diameter 1.5" / 38mm
    Voice Coil Former Material  Kapton
    Winding Material  Aluminum
    Diaphragm Material Polyimide
    Magnet Material Neodymium (N38H)
    Magnet Weight 2.4 oz
    Body Color / Finish Silver / Raw
    Body Material Aluminum
    MEASUREMENT
    Overall Diameter 2.52" / 64mm
    Overall Depth 1.93" / 49.2mm
    Bolt Pattern/Type M34 - 1.34"
    Mounting Depth 1.3" / 33mm
